Thule Omnistor 5200 Awning

Price range: £633.00 through £1,104.29

Save up to £242.70 (18%)

The Thule Omnistor 5200 awning is the wall mounted cassette awning for motorhomes and vans. Lengths 1.92 m to 5.02 m with projection up to 2.50 m. Anodised, Anthracite or White cassette, Mystic Grey fabric. Hand crank, motor can be added later. Supplied and fitted in Poole.

See this set up in our Poole showroom
The UK's largest Thule display, plus Isabella and Telta – Fleetsbridge, Poole, 20 minutes from Bournemouth. Open Mon–Fri 9–5, fitting while you wait.
Plan a visit

🚚 Free UK delivery over £300 · 2–4 working days
🛠️ Thule Installation Specialists — advice & fitting from our Poole workshop
🙋🏻‍♂️ Questions? Call 01202 620427 — real people, Mon–Fri 9–5
🔐 Secure checkout — Visa, Mastercard, PayPal, Apple Pay & Google Pay

Thule Logo in black
Add £300.00 more to get free shipping!

The Thule Omnistor 5200 awning is Thule’s standard wall mounted awning for motorhomes and vans. It is the awning we fit most. The cassette sits close to the vehicle, the spring arms keep the fabric drum tight in wind, and the support legs drop straight down so they never scrape the side of the van. Promobil gave the Omnistor range its 2022 design award.

Choose the 5200 if you want:

  • an awning for a coachbuilt motorhome, panel van conversion or campervan
  • up to 2.50 m of projection
  • a cassette colour that matches the vehicle
  • the option to add a motor, side panels and a room later

Key features

  • Projection up to 2.50 m for real shade and rain cover.
  • Spring arms with tension arms keep the fabric taut and improve wind resistance.
  • Legs lower vertically, so they cannot mark the vehicle.
  • Quick Lock legs set and adjust in seconds.
  • Set the pitch and the awning opens and closes with the van’s sliding door open.
  • Cassette adjustment system so it still closes properly after years of use.
  • Front profile with drainage to shed rain.
  • Motor ready. Add the 12 V motor kit later.
  • Takes a tent rail for a Thule room or LED strip.

Choose your awning

  1. Length. Measure the flat wall space. Lengths run from 1.92 m to 5.02 m. Projection is 1.40 m on the 1.92 m, 1.80 m on the 2.32 m, 2.00 m on the 2.62 m and 2.50 m from 3.02 m up.
  2. Cassette colour. Anodised (silver), Anthracite (black) or White.
  3. Fabric. Mystic Grey.

Most vans need a vehicle specific adapter. See Thule awning adapters or send us the vehicle details and we will confirm what you need.

Specification

Length Projection Weight
1.92 m 1.40 m 14.2 kg
2.32 m 1.80 m 17.0 kg
2.62 m 2.00 m 19.0 kg
3.02 m 2.50 m 22.6 kg
3.52 m 2.50 m 25.4 kg
4.02 m 2.50 m 28.0 kg
4.52 m 2.50 m 30.4 kg
5.02 m 2.50 m 32.8 kg
Mounting Side wall, with vehicle adapter where needed
Operation Hand crank, winding handle included. 12 V motor kit available
Cassette colours Anodised, Anthracite, White
Fabric Mystic Grey
Made in Belgium

Supplied and fitted in Poole

We fit the Omnistor 5200 at our workshop in Poole, Dorset, with the right adapter and brackets. Read about awning fitting or ask for a quote when you order. See it wound out in our showroom first if you like.

Add sides, rooms and spares

The 5200 takes Thule Smart Panels, Rain Blocker and Sun Blocker sides and the Thule room and tent systems. Spares are on the Omnistor 5200 spare parts page, and replacement fabric on the awning fabric page.

Frequently asked questions

Can I add a motor to the Thule Omnistor 5200 later?

Yes. The 12 V motor kit retrofits to the manual awning.

Do I need an adapter?

Most vans do. Flat walled motorhomes often mount directly. Tell us the vehicle and we will confirm.

How does it cope with wind?

Spring arms and tension arms keep the fabric taut. In strong wind, wind the awning in. No awning is built to ride out a gale.

Can I use it with the sliding door open?

Yes. Set the pitch angle and the awning clears the door.

Will it still close properly in ten years?

Yes. The cassette adjustment system takes up wear so the case keeps closing cleanly.

Thule 5200 Awning Features

  • To begin, the design and appearance of the Thule 5200 Awning align with modern recreational vehicles and seamlessly integrate with the vehicle sides.
  • Furthermore, the robust spring arms, equipped with patented tension arms, ensure optimal tensioning of the awning fabric and enhance wind-resistance.
  • With a projection of up to 2.50 m, the awning extends your personal space, shielding you from both sun and rain.
  • Additionally, there is an optional rail available that covers the gap beneath the awning. This rail serves a dual purpose: it allows for the installation of a Thule tent and the addition of a Thule LED Strip.
  • The vertically lowering system enables the deployment of support legs without posing a risk of damage to the vehicle.
  • Featuring a user-friendly Quick Lock system, the support legs can be easily set and adjusted.
  • Moreover, the awning can be opened and closed at your preferred angle, even when the sliding door of your van is open
  • Thanks to the unique Thule cassette adjustment system, the awning can be perfectly closed, maintaining its functionality even after years of use.

Technical Specification

Mounting location Side Wall
Operation Manual or 12v
Retro-fit Motor ✓
Integrated Tension Arms ✓
Cassette Colour White, Anthracite or Anodised
Available Lengths 1.92 – 5.02 m
Projection 1.40 – 2.50 m
Weight 14.2 – 31 kg
Warranty 2 Years
Instructions Thule 5200 Awning

Thule Omnistor 5200 Installation

  • Designed to be fitted vertically, this awning is incredibly versatile.
  • Suitable for vans, caravans & motorhomes.
  • Installation instructions vary on application & vehicle.
  • Retro-fit motor, & LED lighting available.
  • Professional installation is advisable.

Thule Omnistor 5200 Spare Parts Found Here

Thule Awning Spare Parts

Q: Why is my awning handle stuck in my awning?

A: A very common problem! Most users have not been shown how to use the handle properly. Using your fingertips, gently push the handle upwards and then half a turn anti-clockwise. The handle will simply pull out.

Q: Will this awning fit my caravan?

A: There are very few caravans that we would recommend this awning for. For a non drill caravan awning, we strongly recommend the Thule Omnistor 6300.

Q: I currently have a Fiamma awning, will this Thule awning fit the same brackets?

A: Yes, this awning model is compatible with both Fiamma & Dometic brackets. Please note that the LED rail is incompatible with Fiamma brackets.
